X Ray Baggage Scanner Fdt-Se100100 Has Dangerous Liquid Automatic Recognition

X Ray Baggage Scanner Fdt-Se100100 Has Dangerous Liquid Automatic Recognition

Overview X-ray Baggage Scanner FDT-SE100100 FDT X-ray baggage scanners operate based on the x-ray penetration principle.
Basic Info
Model NO. FDT-SE100100
Portable Non Portable
Form Flatbed
Application Security Check, Industrial
Type Industrial High-definition X-ray Detector
Certification CE, ISO
Customized Customized
Alarm Form Display Alarm
Appearance Vertical
Application Industry Security Industry
Product Type Conveyor
Transport Package Package
Specification 3000*1450*1950
Trademark Fjade
Origin Shanghai
HS Code 9022191010
Production Capacity 1000000
Product Description
X-ray Baggage Scanner
FDT-SE100100

X Ray Baggage Scanner Fdt-Se100100 Has Dangerous Liquid Automatic Recognition


FDT X-ray baggage scanners operate based on the x-ray penetration principle. Widely used in national security, which covers the national research institutions, detection centers, courts, prisons, procuratorates , Army, airports, subway and railway stations, docks, schools, embassies, tourist attraction, logistics, big events etc. General Specifications

Dimensions: 3328mm(L)×1315mm (W)×1768.5mm(H)Tunnel size: 1010mm (W)×1010mm (H)Conveyor speed: 0.20-0.22m/sConveyor height: 305mmWeight: 815KgStorage temperature / humidity:-40 ºC ± 3 ºC ~ +60 ºC ± 2 ºC / 5% ~ 95% (no condensation)Operating temperature / humidity:0 ºC ± 3 ºC ~ + 40 ºC ± 2 ºC / 5% ~ 95% (no condensation)Power: AC220 V (-10% to + 10%), 50Hz ± 3HzPower consumption: 1.2KVA

Basic Specifications

Penetration: 30mm Steel Plate(140kV) 34mm Steel Plate(160KV)Wire resolution: 40AWGPenetration resolution: 32AWGSpatial resolution: horizontal Ф1.0mm vertical Ф1.0mm

X Ray generator

Generation direction: Up-Bottom Tube voltage: 140~160kV AdjustableTube current: 0.4~1.2mA Adjustable Cooling/ duty cycle: sealed oil / 100%Generation angle: 80 °

Configuration

International brand electrical componentsIndustrial PLC circuit control, Capacitance integral analog conversion, clear imageIndustrial computer, long-term stable and reliable systemErgonomic principle reading system,Radiation protection system (close to natural background)

Image processing functions
  1. Color / black&white,
  2. Organic / inorganic,
  3. Super enhancement,
  4. Edge enhancement,
  5. Partial enhancement,
  6. Grayscale scanning,
  7. Image restoration,
  8. Zoom in / out,
  9. High / low energy penetration,
  10. Continuous observation,
  11. Playback (50),
  12. Image storage(>10 w pic.)
Others:
  1. One key shut-down,
  2. High density alarm,
  3. Drug and explosive powder detection
  4. Built-in Automatic self-diagnosis
Dimensions

X Ray Baggage Scanner Fdt-Se100100 Has Dangerous Liquid Automatic Recognition

FAQ

OEM and ODM are highly welcome ! Customized

1.Are you manufacturer?
Yes, we are professional manufacturer of security detection system.Strong and durable, good quality ; Satisfactory and considerate service always be the key that we focus .

2.How many series products do you have?
We have 11 security product series:X-Ray Baggage Scanner Body ScannerWalk Through Metal Detector (include Thermal Imaging Temperature Measuring Detector) Hand Held Metal Detector Footwear&Bags Industrial Quality Inspection EquipmentUnder Vehicle Surveillance SystemExplosive &Narcotics DetectorNuclear Radiation DetectorDangerous liquid Detector(include hand-held detector)Disinfection&Temperature SensorExplosion-proof Products

3.Do you have any big projects that you have done?



Conference
Shanghai CPPCC;Wu zhen Internet Conference;The first China Import Expo; The World Swimming Championships in Hangzhou;United Nations Conference on Geographic Information

Transportation
Chi feng High-speed railway station;Gan yu Bus station;Ju lu Passenger Station

Public inspection law,government,enterprises and institutions
People's Court of Southwest Airport Development Zone; Jinan People's Court; Chengdu People's Court; 12 corps agricultural division division; Administrative Committee of Urumqi Development Zone; Ba zhou prison

4. What's your MOQ limit?
Different items no different quantity. We are available for one peices for sample machine.

5.How about the warranty and services?
Provide one year warranty and lifetime technical support.Free on-line training one-on-one in our factory for free.

6. How long is your warranty?
Free warranty :1 year.(Failure of a machine caused by non-human causes)Paid warranty: with no upper limit years.

7. What is your after-sales service?
After-sales service is core of our concern. Our company are providing high-quality service to meet and surpass the clients' expectations.
First: Installation service: our company could provide installation service after our equipment reached the site at clients' need. Our charges will be reasonable and assuring our systems working properly after installation and do commissioning of our systems, provided there are no system damages caused during improper transportation handling or man-made harm.
Second: Training service: We could provide online training service to both our partners and end users at clients' need.
Third: Debugging and Maintenance service: We could provide maintenance service to our clients. Our charges will be reasonable and could assure to issue a maintenance report to the user after maintenance work.(Failure of a machine caused by non-human causes)

We also have several methods of after-sales service available about technical analysis and support for client according to the your preference:
First:On-line (like initiate a video call): We could do on-line technical analysis to the end users' requirements and guide the technician at site to do the repair or maintenance accordingly.
Second:Telephone (like Whats app): We could provide technical guidance service to our clients through Whats app. 24 hours service telephone is available.

8.How about your supply capacity?
We have our own big factory as our total security solutions manufacturing base. Could be able to handling various projects at clients' need.

9.How many days we can get the machine after payment?
Normally, with stock only need 3-5 days for leading time.Without stock, need 10-20 days to manage the production.The mode of transportation depends on the customer's demand.

10. How many ways of transportation and what is your products' package?
We have Ocean freight, Air freight, Land transportation.For package, we usually use the wooden or box and so on.

11. Where is your company? Can I come to visit?
Our factory and office is located in Shanghai, China, you're warmly welcome to visit us.

12.How does your factory do regarding quality control?
We control every production process in accordance with ISO , CE and FCC certification.
